3.5inch TFT LED Portable Monitor & Satellite Finder

TFT LED 3.5 "(89mm) Display size: 73 * 51mm

Dots pixels: 320 * 240 (230400Pixes) DiSEqC: 1.2 edition

LNBinput: F type female head. Input impedance: 75 Ω (F)

Frequency range: 950MHz-2150MHz Signal level:-65dBm ~-25dBm

LNB Power supply: 13/18V, max400mA LNB Switch control: 22KHz

Threshold: 4.1dB Symbol rate: 2Mbps ~ 45Mbps

Demodulation chip: QPSK (SCPC and MCPC compatible)

System processor: 32bit processor (200MHz) SDRAM: 16Mbyte

FLASH: 4Mbyte Video: MPEG-2 Main Level

Rate: up to 15M bits / s Image analysis: 720 * 576,720 * 480

Voice patterns: single sound channel Sampling rate: 32,44.1 and 48KHz

Lithium battery: DC 11.1V 2200mAh (built-in) Input voltage: DC12.5V 1.5A;

Dimensions: 165 * 125 * 80mm Weight: 830g (including battery pack)

Low power consumption LED / high-resolution digital display TFT LCD. Built-in 2200mAh Li-lon battery, do not need an external power supply, working time is about 3-4 hours, USB port for upgrade, AV output and input function. Satellite images and signal quality can be displayed through the LCD and digital dual screen.Unique satellite guidance function, built-in satelliter finder management, 13V/18V/22K Signal lock instruction, With LNB circuit short protection, external short circuit alarm, it can block strong sunshine, which helps image shows more clearly. Due to the adoption of aluminum metal shell, this machine is small in size and light in weight.Equipped with installation tool backpack, it is more convenient to carry, it is a professional equipment for satellite TV receiving system engineering, control engineering and technicians.

12.5V 1.2A DC adapter 1piece

Remote control 1piece

LNB (F Quick plug) 1piece

Operation Manual 1Piece

Bag (optional) 1piece

Car power (optional) 1Piece
